Construction and Feature
XJRO-32 RCBO
●Provides protection against earth fault/leakage current, short-circuit, overload, and function of isolation
● Provides complementary protection against direct contact by human body
● Effectively protects electric equipment against insulating failure
● Provides comprehensive protection to household and commercial distribution systems
- Standard: IEC61009
- Residual current characteristics: AC,A
- Pole No.: 1P+N
- Tripping curve: B,C
- Rated short-circuit capacity:4.5kA
- Rated current (A): 6,10,16,20,25,32
- Rated voltage: 240V AC
- Rated frequency: 50/60Hz
- Rated residual operating current(mA):30
- Tripping duration: instantaneous≤0.1s
- Electro-mechanical endurance 4000cycles
- Connection terminal: pillar terminal with clamp
- Connection capacity. Flexible conductor 10mm2 Rigid conductor 16mm2
- Installation. On symmetrical DIN rail 35mm Panel mounting
